FES 63A OVER AND UNDER VOLTAGE AND CURRENT PROTECTION RELAY PAKISTAN

FES 80A OVER AND UNDER VOLTAGE AND CURRENT PROTECTION RELAY PAKISTAN FES 80A OVER AND UNDER VOLTAGE AND CURRENT PROTECTION RELAY PAKISTAN Bulgaria   Home protection 63A 220V DIN rail voltage adjustable device describe A surge protector like this is manufactured by the well-known brand Mora and is an electrical appliance or device designed to protect electrical equipment from voltage spikes and current spikes. Surge protectors try to limit the voltage supplied to electronic devices by blocking or short-circuiting to ground any unwanted voltage above the safety threshold FES 63A OVER AND UNDER VOLTAGE AND CURRENT PROTECTION RELAY PAKISTAN FES 63A OVER AND UNDER VOLTAGE AND CURRENT PROTECTION RELAY PAKISTAN Specification FES MORA 80A OVER AND UNDER VOLTAGE AND CURRENT PROTECTION RELAY PAKISTAN Rated working current: 63A Overvoltage protection value: AC 230V-AC 275V; the factory default is 275V Undervoltage protection value: AC 160V-AC 220V; factory default is 175V Automatic shutdown delay: 0-30 seconds; the factory default is 30 seconds Overcurrent protection value: 0-63A; factory default is 63A Effective voltage display range 70-400V Effective current display range 0-99.9A Can withstand lightning surge voltage in the 5kV range 8 Modular contour design and rail installation Rated working voltage: AC 230V, 50Hz Maximum short-circuit withstand current: 3000A below 63A, 4500A above 50A (action time 10ms) Action time: 0-30 seconds; the factory default is 30 seconds Own power consumption <1.5 watts Mechanical life of motor: >100,000 times Dimensions: 80 x 37 x 66 mm (length x width x height) Ambient temperature = standard Working environment temperature range: -25℃～55℃ Relative humidity: 45-90% RH: 40 C Latitude: <2000m Pollution degree: Level 2 The package includes: 1x surge VA protector
